Supershooter 16

Home
/
Mobile Units/OBs
/
Supershooter 16

Supershooter 16

NEP | US

Supershooter 16 is an HD mobile unit capable of 1080i and 720p.

SPECIFICATIONSMONITOR WALLSFLOOR PLANS

    specifications

    What’s a Rich Text element?

    The rich text element allows you to create and format headings, paragraphs, blockquotes, images, and video all in one place instead of having to add and format them individually. Just double-click and easily create content.

    Static and dynamic content editing

    A rich text element can be used with static or dynamic content. For static content, just drop it into any page and begin editing. For dynamic content, add a rich text field to any collection and then connect a rich text element to that field in the settings panel. Voila!

    How to customize formatting for each rich text
    • Headings, paragraphs, blockquotes, figures, images, and figure captions can all be styled after a class is added to the rich text element using the "When inside of" nested selector system.
    • ‍Headings, paragraphs, blockquotes, figures, images, and figure captions can all be styled after a class is added to the rich text element using the "When inside of" nested selector system.

    Headings, paragraphs, blockquotes, figures, images, and figure captions can all be styled after a class is added to the rich text element using the "When inside of" nested selector system.

    Vehicle-Specific Information
    • 56' long x 13'6" high x 17' wide - expanded without tractor
    • curbside Expando
    • 400 amp, 208 volt, 3 phase OR 2 200amp, 208 volt, 3 phase
    Production
    • GVG Kayenne K-Frame Switcher, 9 M/E
    • 16 IDPM / eDPM / 2D DPM
    • Still Store Movies
    • Flexkey
    • DoubleTake
    • Elite Package
    Communications
    • Adam Intercom System - 128 Ports
    • 20 dual listen beltpacks
    • 12 single muff headsets
    • 12 double muff headsets
    • 12 IFB beltpacks
    • 6 walkie talkies with 2 base stations
    • 1 phone system with 16 lines
    • 4 ring down phone lines
    • 4 TIF - Telephone Interfaces
    • 6 QKT
    Cameras
    • 11 Sony HDC2500
    • 1 Sony HDC4300
    • 1 Sony HDC1500 Camera
    • 6 Sony HDLA Large Lens Adapters
    • 6 Hard Camera Panhead & Tripod
    • 6 HH Camera Panhead & Tripod
    • 13 CCUs on Board
    • 14 CCUs Wired For
    • 1 Sony PXW-X500 ENG package
    Lenses
    • 2 Canon 100x9.3 Hard Lens
    • 2 Canon 86x9.3 Hard Lens
    • 2 Canon 95x8.6 Hard Lens
    • 4 Canon Lens 21:1 Hand Held Lens
    • 1 Canon 4.7 Wide angle Lens
    • 2 Fujinon 18x5.5 Wide angle Lens
    Support Equipment
    • PESA
    • HD video - 192 inputs x 192 outputs
    • 96 inputs x 96 outputs embed/de-embed (16 channels)
    • MADI 8 inputs x 8 outputs
    • AES 512 inputs x 640 outputs
    • Analog audio 128 inputs x 128 outputs
    • 20 Utility Frame Syncs/Processors
    • 6 HD Video over Fiber Transmitters
    • 5 de-embedders (16-channel)
    • Monitors:
    • 6 - 22" LCD, 4 - 9" SDI
    • Virtual Monitor Walls with The Wall user interface throughout
    Audio
    • Calrec Sigma Digital Audio Console
    • Bluefin DSP Processing
    • 340 Channels with full signal processing
    • 48 Multi-track busses
    • 20 Aux busses
    • 64 Fader, A/B Layers\
    • 2 MADI Ports
    • 1 DTS Neural Up-Mix/Down-Mix Package
    • 2 Digicart
    • 1 CD Player
    Microphones
    • 8 Announcer Headsets
    • 8 Daltech Announce Consoles
    • 6 Short Shotgun Microphones
    • 6 Long Shotgun Microphones
    • 6 Stick Microphones
    • 8 Lavalier Microphones
    Record & Playback
    • 5 EVS XT3 6 Channel LSM 10 GB
    • 1 EVS XT3 6 Channel Spotbox
    • 2 EVS Xhub[3]
    • 1 EVS X-File[3]
    • 1 EVS IP Director
    • 1 EVS XT Access
    • 1 Sony HDW-M1800 HDCam VTR
    • 4 DVD Recorder w/ remote control
    Graphics
    • 1 Chyron Hyper X3
    Cables
    • 12mm SMPTE: 4 -500' 4 -250' 10 -100'
    • 1 SMPTE mult (5x125')
    • Mini Triax: 10 -250' 10 -100' 10 -25'
    • 2 Triax mults
    • DT12 6 -250' 6 -100' 6 -50'
    • 10 DT12 Fanout sets
    • 4 DT12 breakout boxes
    • TAC-12 ST-ST 2 - 250 1 -500' 1 -1500' 3 -150' or less
    • 5 Pair HD Coax Loom 4 -125'
    • Assorted Single Line Coax and XLR Cables
    • 2 sets of 75' 4/0

    monitor walls

    Supershooter 16 Production Monitor Wall
    Supershooter 16 Tape Monitor Wall

    floor plans

    Download Floor Plans
    go up
    Supershooter 16 Floor Plan
